STM32H743 Development Board
STM32H743 Development Board
Regular price
$41.60 USD
Regular price
Sale price
$41.60 USD
Unit price
/
per
Couldn't load pickup availability
-
MCU: STM32H743VIT6, 480MHz , 1MB RAM, 2MB Flash
-
IMU: MPU6000 (SPI1) & ICM42605 (SPI4)
-
Baro: Infineon DPS310 (I2C2)
-
OSD: AT7456E (SPI2)
-
Blackbox: MicroSD card slot (SDIO)
-
7x Uarts (1,2,3,4,6,7,8) with built-in inversion.
-
13x PWM outputs(including “LED” pad)
-
2x I2C
-
1x CAN
-
6x ADC (VBAT, Current, RSSI, Analog AirSpeed, VB2, CU2)
-
3x LEDs for FC STATUS (Blue, Red) and 3.3V indicator(Red)
-
1x SPI3 breakout
-
USB/Beep Extender with Type-C(USB2.0)
-
Dual Camera Inputs switch
-
5V/9V(12V) for Camera/VTX power switch
-
High-precision Current Sense (90A continuous, 220A peak)
-
Battery Voltage Sensor: 1K:10K (Scale 1100 in INAV, BATT_VOLT_MULT 11.0 in ArduPilot)
-
ADC VB2 voltage divider: 1K:20K
-
Static power 160mA@5V
